MET-SHANK W-OUT COOL FOR UN (UNIFIED) INT-RH&LH THREAD; PITCH: 14.00 TPI; SHANK D: 08.00mm; OAL: 064.00mm (2.5"); NECK LEN: ~35.3mm (01.39"); CUT D: ~007.7mm (0.303"); UNC: (7/16"); UNF: 14; FLUTES: 3; : 3xD1; GRADE: MT7

MET-SHANK W-OUT COOL FOR ISO (METRIC) INT-RH&LH THREAD; PITCH: 01.50mm; SHANK D: 08.00mm; OAL: 105.00mm (4.1"); NECK LEN: ~31.5mm (01.24"); CUT D: ~007.8mm (0.307"); M COARSE: M10; M FINE: M14,M16; FLUTES: 3; : 3xD1; GRADE: MT7

MET-SHANK W-OUT COOL FOR ISO (METRIC) INT-RH&LH THREAD; PITCH: 01.50mm; SHANK D: 08.00mm; OAL: 064.00mm (2.5"); NECK LEN: ~31.5mm (01.24"); CUT D: ~007.8mm (0.307"); M COARSE: M10; M FINE: M14,M16; FLUTES: 3; : 3xD1; GRADE: MT7

MET-SHANK W-OUT COOL FOR UN (UNIFIED) INT-RH&LH THREAD; PITCH: 20.00 TPI; SHANK D: 08.00mm; OAL: 064.00mm (2.5"); NECK LEN: ~34.5mm (01.36"); CUT D: ~008.0mm (0.315"); UNF: (7/16"); FLUTES: 3; : 3xD1; GRADE: MT7

MET-SHANK W-OUT COOL FOR ISO (METRIC) INT-RH&LH THREAD; PITCH: 01.50mm; SHANK D: 08.00mm; OAL: 079.00mm (3.1"); NECK LEN: ~41.4mm (01.63"); CUT D: ~008.0mm (0.315"); M COARSE: M10; M FINE: M14,M16; FLUTES: 3; : 4xD1; GRADE: MT7

MET-SHANK W-OUT COOL FOR UN (UNIFIED) INT-RH&LH THREAD; PITCH: 13.00 TPI; SHANK D: 10.00mm; OAL: 073.00mm (~2.87"); NECK LEN: 40.10mm (~1.58"); CUT D: 09.20mm (~0.36"); UNC: (1/2); FLUTES: 3; GRADE: MT7

MET-SHANK W-OUT COOL FOR ISO (METRIC) INT-RH&LH THREAD; PITCH: 01.75mm; SHANK D: 10.00mm; OAL: 073.00mm (2.9"); NECK LEN: ~37.8mm (01.49"); CUT D: ~009.0mm (0.354"); M COARSE: M12; FLUTES: 3; : 3xD1; GRADE: MT7

MET-SHANK W-OUT COOL FOR ISO (METRIC) INT-RH&LH THREAD; PITCH: 02.00mm; SHANK D: 10.00mm; OAL: 073.00mm (2.9"); NECK LEN: ~30.0mm (01.18"); CUT D: ~010.0mm (0.394"); M COARSE: M14; M FINE: M17; FLUTES: 4; : 2xD1; GRADE: MT7

MET-SHANK W-OUT COOL FOR UN (UNIFIED) INT-RH&LH THREAD; PITCH: 12.00 TPI; SHANK D: 12.00mm; OAL: 105.00mm (~4.13"); NECK LEN: 45.00mm (~1.77"); CUT D: 10.50mm (~0.41"); UNC: (9/16); FLUTES: 3; GRADE: MT7

MET-SHANK W-OUT COOL FOR UN (UNIFIED) INT-RH&LH THREAD; PITCH: 11.00 TPI; SHANK D: 12.00mm; OAL: 105.00mm (~4.13"); NECK LEN: 50.00mm (~1.97"); CUT D: 11.40mm (~0.45"); UNC: (5/8); FLUTES: 3; GRADE: MT7

MET-SHANK W-OUT COOL FOR ISO (METRIC) INT-RH&LH THREAD; PITCH: 02.00mm; SHANK D: 12.00mm; OAL: 105.00mm (4.1"); NECK LEN: ~50.0mm (01.97"); CUT D: ~011.8mm (0.465"); M COARSE: M16; M FINE: M18,M20; FLUTES: 4; : 3xD1; GRADE: MT7

MET-SHANK W-OUT COOL FOR UN (UNIFIED) INT-RH&LH THREAD; PITCH: 18.00 TPI; SHANK D: 12.00mm; OAL: 105.00mm (4.1"); NECK LEN: ~49.0mm (01.93"); CUT D: ~012.0mm (0.472"); UNF: (5/8"); FLUTES: 4; : 3xD1; GRADE: MT7

MET-SHANK W-OUT COOL FOR UN (UNIFIED) INT-RH&LH THREAD; PITCH: 10.00 TPI; SHANK D: 16.00mm; OAL: 105.00mm (4.1"); NECK LEN: ~59.7mm (02.35"); CUT D: ~014.4mm (0.567"); UNC: (3/4"); UNF: 10; FLUTES: 4; : 3xD1; GRADE: MT7
