IN-SHANK W-OUT COOL FOR ISO (METRIC) INT-RH&LH THREAD; PITCH: 00.80mm; SHANK D: 0.250"; OAL: 2.5" (064.00mm); NECK LEN: 0.49" (~12.4mm); CUT D: 0.150" (~003.8mm); M COARSE: M5; FLUTES: 3; : 2xD1; GRADE: MT7

IN-SHANK W-OUT COOL FOR ISO (METRIC) INT-RH&LH THREAD; PITCH: 00.70mm; SHANK D: 0.250"; OAL: 2.5" (064.00mm); NECK LEN: 0.49" (~12.4mm); CUT D: 0.122" (~003.1mm); M COARSE: M4; FLUTES: 3; : 3xD1; GRADE: MT7

IN-SHANK W-OUT COOL FOR UN (UNIFIED) INT-RH&LH THREAD; PITCH: 24.00 TPI; SHANK D: 0.250"; OAL: 2.5" (064.00mm); NECK LEN: 0.42" (~10.7mm); CUT D: 0.138" (~003.5mm); UNC: 10,12; FLUTES: 3; : 2xD1; GRADE: MT7

IN-SHANK W-OUT COOL FOR UN (UNIFIED) INT-RH&LH THREAD; PITCH: 32.00 TPI; SHANK D: 0.250"; OAL: 2.5" (064.00mm); NECK LEN: 0.41" (~10.4mm); CUT D: 0.146" (~003.7mm); UNF: 10; FLUTES: 3; : 2xD1; GRADE: MT7

IN-SHANK W-OUT COOL FOR UN (UNIFIED) INT-RH&LH THREAD; PITCH: 32.00 TPI; SHANK D: 0.250"; OAL: 2.5" (064.00mm); NECK LEN: 0.41" (~10.4mm); CUT D: 0.100" (~002.5mm); UNC: 6; FLUTES: 3; : 3xD1; GRADE: MT7

IN-SHANK W-OUT COOL FOR UN (UNIFIED) INT-RH&LH THREAD; PITCH: 32.00 TPI; SHANK D: 0.250"; OAL: 2.5" (064.00mm); NECK LEN: 0.37" (~09.4mm); CUT D: 0.126" (~003.2mm); UNC: 8; FLUTES: 3; : 2xD1; GRADE: MT7

IN-SHANK W-OUT COOL FOR ISO (METRIC) INT-RH&LH THREAD; PITCH: 00.50mm; SHANK D: 0.250"; OAL: 2.5" (064.00mm); NECK LEN: 0.37" (~09.4mm); CUT D: 0.093" (~002.4mm); M COARSE: M3; FLUTES: 3; : 3xD1; GRADE: MT7

IN-SHANK W-OUT COOL FOR ISO (METRIC) INT-RH&LH THREAD; PITCH: 00.70mm; SHANK D: 0.250"; OAL: 2.5" (064.00mm); NECK LEN: 0.35" (~08.9mm); CUT D: 0.122" (~003.1mm); M COARSE: M4; FLUTES: 3; : 2xD1; GRADE: MT7

IN-SHANK W-OUT COOL FOR UN (UNIFIED) INT-RH&LH THREAD; PITCH: 40.00 TPI; SHANK D: 0.250"; OAL: 2.5" (064.00mm); NECK LEN: 0.31" (~07.9mm); CUT D: 0.083" (~002.1mm); UNC: 4; FLUTES: 3; : 3xD1; GRADE: MT7

IN-SHANK W-OUT COOL FOR UN (UNIFIED) INT-RH&LH THREAD; PITCH: 32.00 TPI; SHANK D: 0.250"; OAL: 2.5" (064.00mm); NECK LEN: 0.28" (~07.1mm); CUT D: 0.100" (~002.5mm); UNC: 6; FLUTES: 3; : 2xD1; GRADE: MT7

IN-SHANK W-OUT COOL FOR UN (UNIFIED) INT-RH&LH THREAD; PITCH: 40.00 TPI; SHANK D: 0.250"; OAL: 2.5" (064.00mm); NECK LEN: 0.25" (~06.3mm); CUT D: 0.083" (~002.1mm); UNC: 4; FLUTES: 3; : 2xD1; GRADE: MT7

MET-SHANK W-OUT COOL FOR UN (UNIFIED) INT-RH&LH THREAD; PITCH: 32.00 TPI; SHANK D: 06.00mm; OAL: 058.00mm (2.3"); NECK LEN: ~17.5mm (0.69"); CUT D: ~003.2mm (0.126"); UNC: 8; FLUTES: 3; : 4xD1; GRADE: MT7

IN-SHANK W-OUT COOL FOR UN (UNIFIED) INT-RH&LH THREAD; PITCH: 20.00 TPI; SHANK D: 0.250"; OAL: 2.5" (064.00mm); NECK LEN: 0.55" (~14.0mm); CUT D: 0.187" (~004.7mm); UNC: (1/4); UNF: 20; FLUTES: 3; : 2xD1; GRADE: MT7

MET-SHANK W-OUT COOL FOR UN (UNIFIED) INT-RH&LH THREAD; PITCH: 24.00 TPI; SHANK D: 06.00mm; OAL: 058.00mm (2.3"); NECK LEN: ~15.5mm (0.61"); CUT D: ~003.5mm (0.138"); UNC: 10,12; FLUTES: 3; : 3xD1; GRADE: MT7

MET-SHANK W-OUT COOL FOR UN (UNIFIED) INT-RH&LH THREAD; PITCH: 28.00 TPI; SHANK D: 06.00mm; OAL: 105.00mm (4.1"); NECK LEN: ~19.0mm (0.75"); CUT D: ~005.0mm (0.197"); UNF: (1/4); FLUTES: 3; : 3xD1; GRADE: MT7

MET-SHANK W-OUT COOL FOR ISO (METRIC) INT-RH&LH THREAD; PITCH: 01.00mm; SHANK D: 06.00mm; OAL: 105.00mm (4.1"); NECK LEN: ~20.1mm (0.79"); CUT D: ~004.6mm (0.183"); M COARSE: M6; M FINE: M8; FLUTES: 3; : 3xD1; GRADE: MT7

MET-SHANK W-OUT COOL FOR UN (UNIFIED) INT-RH&LH THREAD; PITCH: 20.00 TPI; SHANK D: 06.00mm; OAL: 105.00mm (4.1"); NECK LEN: ~19.0mm (0.75"); CUT D: ~004.7mm (0.187"); UNC: (1/4); UNF: 20; FLUTES: 3; : 3xD1; GRADE: MT7

MET-SHANK W-OUT COOL FOR ISO (METRIC) INT-RH&LH THREAD; PITCH: 00.80mm; SHANK D: 06.00mm; OAL: 105.00mm (4.1"); NECK LEN: ~16.0mm (0.63"); CUT D: ~003.8mm (0.150"); M COARSE: M5; FLUTES: 3; : 3xD1; GRADE: MT7

MET-SHANK W-OUT COOL FOR UN (UNIFIED) INT-RH&LH THREAD; PITCH: 32.00 TPI; SHANK D: 06.00mm; OAL: 105.00mm (4.1"); NECK LEN: ~15.0mm (0.59"); CUT D: ~003.7mm (0.146"); UNF: 10; FLUTES: 3; : 3xD1; GRADE: MT7

SOLID CARBIDE LONG METRIC SHANK MILL-THREAD CUTTING TOOL WITH 3 FLUTES FOR UN THREADING; PITCH: 24.00 TPI; SHANK DIA. (d): 06.00mm; CUTTING DIA. (D): 03.50mm; APPROXIMATE CUTTING LENGTH: 15mm; GRADE: MT7
