16mm (3/8" I.C.) CHIPBREAKER LAYDOWN INSERT FOR 55-DEG PART PROF INT-RH THREAD; PITCH: 08.00 TPI - 48.00 TPI,00.50mm - 03.00mm; GRADE: BMA;

16mm (3/8" I.C.) CHIPBREAKER LAYDOWN INSERT FOR 60-DEG PART PROF INT-RH THREAD; PITCH: 08.00 TPI - 48.00 TPI,00.50mm - 03.00mm; GRADE: BMA;

22mm (1/2" I.C.) LAYDOWN INSERT FOR 60-DEG PART PROF EXT-RH THREAD; PITCH: 05.00 TPI - 07.00 TPI,03.50mm - 05.00mm; GRADE: BMA;

22mm (1/2" I.C.) LAYDOWN INSERT FOR 60-DEG PART PROF INT-RH THREAD; PITCH: 05.00 TPI - 07.00 TPI,03.50mm - 05.00mm; GRADE: BMA;

22Umm (1/2U" I.C.) U-TYPE LAYDOWN INSERT FOR 60-DEG PART PROF INT&EXT-RH&LH THREAD; PITCH: 03.25 TPI - 04.50 TPI,05.50mm - 08.00mm; GRADE: BMA;

27mm (5/8" I.C.) LAYDOWN INSERT FOR 60-DEG PART PROF EXT-RH THREAD; PITCH: 04.00 TPI - 04.50 TPI,05.50mm - 06.00mm; GRADE: BMA;

27Umm (5/8U" I.C.) U-TYPE LAYDOWN INSERT FOR 60-DEG PART PROF INT&EXT-RH&LH THREAD; PITCH: 02.75 TPI - 04.00 TPI,06.50mm - 09.00mm; GRADE: MXC;

M-SHNK FOR UN INT-RH&LH THD;P:20TPI;SHNK:8mm;OAL:64mm(2.5");NECKLN:~15.5mm(.61");CUT D:~4.8mm(.189");CHMF-TRD:~1.2mm(.049");CH H:~.4mm(.016");A:45D;UN:(1/4)-(3/8);UNC:(1/4)-(3/8);UNF:(1/4)-(3/8);UNEF:(1/4)-(3/8);UNS:(1/4)-(3/8);FLUTE:3;2xD1;GR:MT11;LH M04

MET-SHANK W-OUT COOL FOR INT&EXT-RH&LH SPOTTING & DRILLING & SIDE MILLING & CHMF & SLOTTING & GRV & ENGRAVING; SHANK D: 04.00mm; CUT D: ~3mm (0.118"); A: 90-DEG; CUT L: ~6.1mm (0.24"); WEB THICKNESS: ~0.3mm (0.012"); GRADE: CR3;

MET-SHANK W-OUT COOL FOR INT&EXT-RH&LH SPOTTING & DRILLING & SIDE MILLING & CHMF & SLOTTING & GRV & ENGRAVING; SHANK D: 05.00mm; CUT D: ~4mm (0.157"); A: 90-DEG; CUT L: ~7.87mm (0.31"); WEB THICKNESS: ~0.41mm (0.016"); GRADE: CR3;

MET-SHANK W-OUT COOL FOR INT&EXT-RH&LH SPOTTING & DRILLING & SIDE MILLING & CHMF & SLOTTING & GRV & ENGRAVING; SHANK D: 06.00mm; CUT D: ~5mm (0.197"); A: 90-DEG; CUT L: ~9.91mm (0.39"); WEB THICKNESS: ~0.51mm (0.020"); GRADE: CR3;

MET-SHANK W-OUT COOL FOR INT&EXT-RH&LH SPOTTING & DRILLING & SIDE MILLING & CHMF & SLOTTING & GRV & ENGRAVING; SHANK D: 08.00mm; CUT D: ~6mm (0.236"); A: 90-DEG; CUT L: ~11.94mm (0.47"); WEB THICKNESS: ~0.61mm (0.024"); GRADE: CR3;

MET-SHANK W-OUT COOL FOR INT&EXT-RH&LH SPOTTING & DRILLING & SIDE MILLING & CHMF & SLOTTING & GRV & ENGRAVING; SHANK D: 10.00mm; CUT D: ~8mm (0.315"); A: 90-DEG; CUT L: ~16mm (0.63"); WEB THICKNESS: ~0.79mm (0.031"); GRADE: CR3;

MET-SHANK W-OUT COOL FOR INT&EXT-RH&LH SPOTTING & DRILLING & SIDE MILLING & CHMF & SLOTTING & GRV & ENGRAVING; SHANK D: 12.00mm; CUT D: ~10mm (0.394"); A: 90-DEG; CUT L: ~18.03mm (0.71"); WEB THICKNESS: ~0.99mm (0.039"); GRADE: CR3;

MET-SHANK W-OUT COOL FOR INT&EXT-RH&LH SPOTTING & DRILLING & SIDE MILLING & CHMF & SLOTTING & GRV & ENGRAVING; SHANK D: 12.00mm; CUT D: ~12mm (0.472"); A: 90-DEG; CUT L: ~20.07mm (0.79"); WEB THICKNESS: ~1.19mm (0.047"); GRADE: CR3;

MFL Bars Face Grooving

H5 MET-SHANK LD BAR W-COOL FOR 60DEG P-PROF INT-RH THREAD; PITCH: 20TPI-24TPI; SHANK:5mm; OAL:~50.8mm(2"); NECK LEN:~22.1mm(.87"); CUT D:~2.29mm(.09"); MN BORE:~5.08mm(.20"); A:60DEG; HOLDER:SIM...H5; GRADE:BXC;

IN-SHANK W-OUT COOL FOR ISO (METRIC) INT-RH&LH THREAD; PITCH: 00.50mm; SHANK D: 0.250"; OAL: 2.5" (064.00mm); CUT D: 0.087" (~002.21mm); CUT L: 0.21" (05.3mm); M COARSE: 3; M FINE: 4; FLUTES: 3; GRADE: MT7

IN-SHANK W-OUT COOL FOR UN (UNIFIED) INT-RH&LH THREAD; PITCH: 32.00 TPI; SHANK D: 0.250"; OAL: 2.5" (064.00mm); CUT D: 0.126" (~003.2mm); CUT L: 0.27" (~06.9mm); UNC: 8; UNF: 10; FLUTES: 3; : 12; GRADE: MT7

IN-SHANK W-OUT COOL FOR UN (UNIFIED) INT-RH&LH THREAD; PITCH: 40.00 TPI; SHANK D: 0.250"; OAL: 2.5" (064.00mm); CUT D: 0.098" (~002.5mm); CUT L: 0.24" (~06.1mm); UNC: 5; FLUTES: 3; GRADE: MT7
